| Abb.
- Nr. |
Teile
- Nr. |
Beschreibung |
CBX B |
CBX C |
Areacode |
| 1 |
16080-461-751 |
O-Ring |
|
1 |
|
| 2 |
16081-471-831 |
Tasse |
|
1 |
|
| 3 |
16950-MA2-771 |
Hahneinheit |
|
1 |
|
| 4 |
16950-469-005 |
Hahneinheit |
1 |
|
|
| 5 |
16951-MA2-771 |
Körper Hahn |
|
1 |
|
| 6 |
16951-469-005 |
Körper Hahn NLA |
1 |
|
|
| 7 |
16952-MA2-771 |
Siebset |
|
1 |
|
| 8 |
16952-469-005 |
Siebset |
1 |
|
|
| 9 |
16955-469-000 |
Siebset |
1 |
1 |
|
| 10 |
16959-461-751 |
Siebset |
|
1 |
|
| 11 |
175A1-MA2-000ZA |
Tank NH-110M-U |
1 |
|
|
| |
175A1-MA2-610ZA |
Tank NH-113P-A |
1 |
|
DK,DM,E,ED,F,G,SA,U |
| |
175A1-MA2-710ZA |
Tank NH-110M-U NLA |
|
1 |
DK,DM,E,ED,F,G,SA,U |
| |
175A1-MA2-770ZA |
Tank NH-113P-A NLA |
|
1 |
|
| 12 |
17508-422-000 |
Hülse |
2 |
2 |
|
| 13 |
17509-422-000 |
Gummi |
2 |
2 |
|
| 14 |
17541-422-000 |
Mulde |
2 |
2 |
|
| 15 |
17545-323-010 |
Clip |
2 |
2 |
|
| 16 |
17611-422-000 |
Gummidämpfer |
2 |
2 |
|
| 17 |
17613-422-000 |
Scheibe, Dämpfung |
2 |
2 |
|
| 18 |
17615-422-000 |
Halterung |
1 |
1 |
|
| 19 |
17620-??0-027 |
Tankdeckel |
1 |
1 |
|
| 20 |
87560-2?1-760ZB |
Aufkleber |
1 |
1 |
CM,DK,DM,E,ED,G,SA,U |
| |
87560-463-830ZB |
Aufkleber NH-0 |
1 |
1 |
F |
| 21 |
95002-02120 |
Clip B12 |
2 |
2 |
|
| 22 |
95700-06025-08 |
Flanschschraube 6x25 |
2 |
2 |
|
| 23 |
95700-08016-08 |
Flanschschraube 8x16 |
1 |
1 |
|
