| Abb.
- Nr. |
Teile
- Nr. |
Beschreibung |
CBX B |
CBX C |
Areacode |
| 1 |
17963-422-000 |
Chokezughalter |
1 |
1 |
|
| 2 |
22870-MA2-670 |
Chokezug komp |
1 |
1 |
CM |
| |
22870-422-000 |
Chokezug komp |
1 |
1 |
DK,DM,E,ED,F,G,SA,U |
| 3 |
32161-404-000 |
Band B1, Kabel |
2 |
|
|
| 4 |
35130-MA2-670 |
Schalter, Starter Kill |
1 |
1 |
CM |
| |
35150-MA2-600 |
Schalter, Starter Kill |
1 |
1 |
DK,DM,E,ED,F,G,SA,U |
| 5 |
35200-MA2-600 |
Schalter, Blinker |
1 |
1 |
DK,DM,E,ED,F,G,SA,U |
| |
35200-MA2-670 |
Schalter, Blinker
NLA |
1 |
1 |
CM |
| 6 |
35330-413-003 |
Schalter Kupplung |
1 |
1 |
|
| 7 |
46465-422-000 |
Kabelclip |
1 |
1 |
|
| 8 |
53141-422-000 |
Rohr, Gasgriff |
1 |
1 |
|
| 9 |
53165-422-000 |
Griff R |
1 |
1 |
|
| 10 |
53166-422-000 |
Griff L |
1 |
1 |
|
| 11 |
53170-MA2-000 |
Halterung, Griff |
1 |
1 |
|
| 12 |
53174-116-670 |
Stopfen |
1 |
|
|
| |
53174-463-770 |
Stopfen |
|
1 |
|
| 13 |
53178-422-020 |
Kupplungsgriff |
1 |
1 |
|
| 14 |
53180-422-020 |
Schutzgummi |
1 |
1 |
|
| 15 |
53192-422-000 |
Einstellschraube |
1 |
1 |
|
| 16 |
90113-438-000 |
Achsbolzen, Kupplung |
1 |
1 |
|
| 17 |
90321-422-000 |
Kontermutter |
1 |
1 |
|
| 18 |
93481-06025-07 |
Schraube-Scheibe 6x25 |
1 |
1 |
|
| 19 |
93891-05028-07 |
Schraube-Scheibe 5x28 |
2 |
2 |
|
| 20 |
93891-05045-07 |
Schraube-Scheibe 5x45 |
4 |
4 |
|
| 21 |
93893-05018-07 |
Schraube-Scheibe 5x18 |
1 |
1 |
|
| 22 |
94002-06000-0S |
Mutter 6mm |
1 |
1 |
|
