| Abb. - Nr. | Teile - Nr. | Beschreibung | CBX B | CBX C | Area Code |
| 1 | 16010-469-004 | Dichtset | 6 | 6 | |
| 2 | 16011-422-004 | Ventilset Schwimmer | 6 | 6 | |
| 3 | 16012-MA2-611 | Nadelset, Düse | 6 | 6 | DK,DM,E,ED,F,G,SA,U |
| 16012-469-004 | Nadelset, Düse | 6 | 6 | CM | |
| 4 | 16013-679-005 | Schwimmerset | 6 | 6 | |
| 5 | 16015-422-004 | Kammerset A | 2 | 2 | |
| 6 | 16016-402-004 | Schraubenset A | 6 | 6 | DK,DM,E,ED,F,G,SA,U |
| 16016-463-661 | Schraubenset A | 6 | 6 | CM | |
| 7 | 16021-422-004 | Membranset, Beschleunigerpumpe | 1 | 1 | |
| 8 | 16022-469-004 | Kolbenset 1/6 | 2 | 2 | |
| 9 | 16023-422-004 | Kammerset B | 1 | 1 | |
| 10 | 16029-413-004 | Schraubenset C | 5 | 5 | |
| 11 | 16038-422-004 | Schraubenset D | 6 | 6 | |
| 12 | 16044-469-004 | Kolbenset 2/3/4/5 | 4 | 4 | |
| 13 | 16045-422-004 | Kammerset C | 3 | 3 | |
| 14 | 16048-MA2-004 | Ventilset Luftabsperrventil | 1 | 1 | |
| 15 | 16050-422-004 | Feder Vakuumkolben | 6 | 6 | |
| 16 | 16143-469-004 | Kraftstoffschlauch 3.5x120 | 2 | 2 | |
| 17 | 16144-469-004 | Kraftstoffschlauch 3.5x60 | 4 | 4 | |
| 18 | 16165-417-004 | Nadelhalter | 6 | 6 | |
| 19 | 16310-469-000 | Verbindungsstück Überlauf | 2 | 2 | |
| 20 | 93892-04010-00 | Schraube-Scheibe 4x10 | 2 | 2 | |
| 21 | 93892-04012-00 | Schraube-Scheibe 4x12 | 3 | 3 | |
| 22 | 93892-04014-00 | Schraube-Scheibe 4x14 | 6 | 6 | |
| 23 | 93892-04016-00 | Schraube-Scheibe 4x16 | 18 | 18 | |
| 24 | 93892-05016-00 | Schraube-Scheibe 5x16 | 12 | 12 | |
| 25 | 95002-02070 | Clip B7 | 12 | 12 | |
| 26 | 95002-02100 | Clip B10 | 2 | 2 | |
| 27 | 95005-80430-10 | Schlauch 8x430 | 1 | 1 | |
| 28 | 95005-80560-20 | Schlauch 8x560 | 1 | 1 | |
| 29 | 99102-393-1050 | Sekundärhauptdüse | 6 | 6 | |
| 30 | 99103-MA4-0350 | Slow Jet #35 | 6 |
